Workflow Control nodes
These nodes control execution flow — branching, looping, delaying, pausing for approval. They form the skeleton around which you build. Most are Pro tier.
Triggers
| Node | Key | Tier | Description |
|---|---|---|---|
| Manual run | workflow.manual | free | Run the workflow manually from the WP admin. The trigger payload contains who started it and when. |
| Scheduled run | workflow.scheduled | free | Run on a recurring schedule (every N minutes/hours/days). Cron-based; respects WordPress cron accuracy. |
| Workflow completed | workflow.on_complete | free | Trigger when the workflow itself finishes (success, partial, failed, or cancelled). Use for cleanup, logging, or chaining workflows. |
Flow control
| Node | Key | Tier | Description |
|---|---|---|---|
| Condition | workflow.router | pro | Branch yes/no by comparing two values with the configured operator (equals, greater than, contains, regex, etc.) |
| Merge branches | workflow.merge | pro | Continue from whichever upstream branch reached this node. Passthrough — no config. |
| Loop items | workflow.loop_items | pro | Iterate over an array. Nodes placed inside the loop execute once per item. Access the current item via {{loop.item}}. Max 1000 iterations. |
| Batch window | workflow.batch_window | pro | Slice a large list into bounded windows (e.g. 50 items per batch). Each window runs as one execution iteration. |
| Try / Catch | workflow.try_catch | pro | Open an error scope: if anything inside try fails, execution routes to catch instead of crashing the workflow. then runs regardless. |
| Retry block | workflow.retry_block | pro | On failure, re-enqueue the enclosed branch with exponential backoff (configurable initial delay, backoff factor, max delay, max attempts). |
| Approval gate | workflow.approval_gate | pro | Pause the workflow until an authorised user approves or rejects. Shows a summary card in WP admin and can send an email to the approver. Has optional auto-approve timeout and cancel-after deadline. |
| Run another workflow | workflow.run_child | pro | Trigger a reusable (function) workflow from this workflow. Pass arguments, receive return value. |
Delay & stop
| Node | Key | Tier | Description |
|---|---|---|---|
| Delay | workflow.delay | pro | Pause the workflow for a configurable number of seconds/minutes/hours/days. Enqueues a resume job. |
| Wait until date | workflow.wait_until | pro | Pause until a specific timestamp. Accepts ISO-8601 or Unix timestamps. |
| Stop workflow | workflow.stop | free | Terminate the current execution intentionally. Use as a dead-end terminal node. |
| Note | workflow.note | free | Add a documentation comment inside the canvas. Rendered as a sticky note. No runtime effect. |
Variables
| Node | Key | Tier | Description |
|---|---|---|---|
| Set variable | workflow.set_variable | free | Write a value into a flow-scoped variable identified by name. Variables persist for the duration of one execution. |
| Read variable | workflow.get_variable | free | Emit the current value of a flow-scoped variable. Pair with Set variable anywhere upstream. |
Versioning
| Node | Key | Tier | Description |
|---|---|---|---|
| Create workflow version | workflow.version_snapshot | pro | Persist a snapshot of the current workflow definition. Stored as a WordPress revision. |
Use variables instead of chaining merge nodes when you need
to pass data between branches that are far apart. Variables can be
read from any downstream node.
